ipf electronic opti-check Technical Documentation Manual page 330

Integr. Flash
OC53962x / OC53972x / OC53982x / OC539F2x /
OC539G2x / OC539H2x
controller
Voltage (permanent)
Voltage (pulsed)
I
max
Current (permanent)
(+/-10 %, at least +/- 100 mA, at 25 °C)
I
max
Current (pulsed)
(+10/-20 %, at least +/- 100 mA, at 25 °C)
Flash time Max. 1 ms (Duty Cycle max. 1:10)
Operating
OC53962x / OC53972x / OC53982x / OC539F2x /
conditions OC539G2x / OC539H2x
Operating
Operating temperature: +5 ... +50 °C @ measuring point, storage temperature: -20 ... +70 °C
temperature
0 ... 90 % (non-condensing)
Humidity
IP 67 (OC53962x / OC53982x / OC53972x /
Protection class
OC539F2x / OC539H2x / OC539G2x: with tube)
Vibration load IEC 60068-2-6, IEC 60068-2-64
Mech. shock
EN 60068-2-27
resistance
OC53962x / OC53972x / OC53982x / OC539F2x /
Mechanical data
OC539G2x / OC539H2x
Width × Height ×
53 mm × 99.5 mm × 49.8 mm (without lens / tube)
Depth
Material Housing: Aluminium, cover glass tube: PMMA
Weight 300 g (without lens / tube)
Code types / OCR
Modell: OC539G2x / OC53972x
7)
Barcode 2/5 Industrial, 2/5 Interleaved, Codabar, Code 39, Code 93, Code 128, PharmaCode
EAN 8, EAN 13, UPC-A, UPC-E: Base code + variants Add-On 2, Add-On 5
GS1 DataBar (RSS): Limited, Expanded, Expanded Stacked
GS1 DataBar (RSS-14): Base code + variants Truncated, Stacked, Stacked Omnidir
GS1 128
7)
Matrix code DataMatrix (ECC 200), GS1-DataMatrix, QR, PDF417
Optional fonts (recommended: sans serif, proportional), dot matrix, characters: A-Z a-z 0-9 + -. : /
8)
Font
( )
6)
for OC538D2x / OC53842x / OC538E2x / OC53812x / OC538320 with infra-red illumination: 780 nm daylight filter built-
in
7)
incl. quality rating of all barcodes according to ISO / IEC 15416 as well as all matrix codes according to ISO / IEC
15415 or AIM DPM-1-2006
8)
OC539G2x / OC53972x / OC539E2x / OC539320 / OC538320 / OC539C24 only
v2.8.2-K11
12 VDC or 24 VDC
48 VDC
24 VDC or
= 800 mA at 24 VDC
= 4 A at 48 VDC
OC53942x / OC53952x / OC5394V0 /
OC539D2x / OC539E2x / OC53842x /
OC538520 / OC538D2x / OC538E2x |
OC53912x / OC53812x | OC53922x /
OC539320 / OC539C24 / OC538320
53 mm × 99,5 mm (IP 69K: 107,5 mm)
× 38 mm
Housing: Aluminium (IP 69K: Stainless
steel 1.4404) Cover glass: PMMA
250 g (IP69K 700 g)
330/332
Technical Documentation
OC53942x / OC53952x / OC5394V0 /
OC539D2x / OC539E2x / OC53842x /
OC538520 / OC538D2x / OC538E2x |
OC53912x / OC53812x | OC53922x /
OC539320 / OC539C24 / OC538320
–
–
–
OC53942x / OC53952x / OC5394V0 /
OC539D2x / OC539E2x / OC53842x /
OC538520 / OC538D2x / OC538E2x |
OC53912x / OC53812x | OC53922x /
OC539320 / OC539C24 / OC538320
IP 67, IP 69K (depending on model)
OC53952x / OC538520 / OC539E2x /
OC538E2x / OC539320 / OC538320 /
OC53922x
ipf electronic GmbH
Lüdenscheid, Germany
opti-check
6)
