ipf electronic opti-check Technical Documentation Manual page 299

Data element Direction
Device status Device
Current job Device
number
Action status Device
v2.8.2-K11
Type Length
(byte)
PLC UINT8 1
PLC UINT8 1
PLC UINT8 1
Description
Status word, corresponds with the "GS" process
interface command
Bit 0 TRG ready
0: Trigger not permitted,
1: Trigger permitted
Bit 1 Teach
0: Teach will not be carried out with
the next image recorded
1: Teach will be carried out with the
next image recorded
Bits 2..3 Mode
0: Run mode
1: Set-up mode
2: Test mode
Bit 4 ImgProcAct
0: Image acquisition/analysis not
active
1: Image acquisition/analysis active
Bits 5..7:
Reserved (always 0)
Current job number 1..255,
0: if not in run mode or if job switching is active,
corresponds with the "GS" process interface
command
Status for various actions, corresponds with the
"GS" process interface command
Bits 0..1 Job switching status
0: Idle (no request pending),
1: in progress
2: completed successfully
3: completed with errors
Bits 2..3 SetParam status
0: idle (no request pending)
1: in progress
2: completed successfully
3: completed with errors
Bits 4..5 SwitchMode status
0: idle (no request pending),
1: in progress
2: completed successfully
3: completed with errors
Bit 6..7 Reserved (always 0)
299/332
