15.4.5 GI command – access an image (only via Ethernet)
This function enables you to access live images and defect images with and without the field of view.
Example
Structure of the command PLC
Command Parameters
G I 0
Get Image
2 byte ASCII hex
00 = live image
01 = Live image with
field of view
80 = Fault image
81 = Fault image with
field of view
Structure of the Response PLC
Response
R I 0
Response 2 byte ASCII
Image hex
00 = live image
01 = Live image
with field of view
80 = Fault image
81 = Fault image
with field of view
v2.8.2-K11
device
0 0
2 byte ASCII hex
image number
00 = Last image,
01 = penultimate
image,
02 = ...
device
0 0 0
2 byte ASCII
hex
Image number
0
0 0 0 4 F
8 byte ASCII hex
Length of the image data
276/332
Technical Documentation
...
6 1 6
data in
the format
BMP
