Confirm your settings and return to the feature list with OK. Return to the feature list without making
any changes with Cancel.
This feature check has the following output values for the datagram at the process interface:
Output value Data type
Result
Conformity Integer
Centre of object Float point
Angle of object's
Float
rotation
v2.8.2-K11
Description
Result of the feature check: "P" (Pass); "F" (Fail)
Match of the model (%)
Position of the object in the image (px)
Angle of the object (degrees)
