ipf electronic opti-check Technical Documentation Manual page 300

Data element Direction
Device
Job results
v2.8.2-K11
Type Length
(byte)
PLC
UINT32 4
300/332
Description
1 bit "Pass" and 1 bit "Fail" for each total and partial
result, if both bits=0 -> no result available
Bit 0 1 if the total result = "Pass", otherwise
0
Bit 1 1 if the total result = "Fail", otherwise
0
Bit 2 1 if a process alarm was produced
during image analysis (details ->
ProcessAlarm), otherwise 0
Bits 3..15 Reserved (always 0)
Bit 16 1 if partial result 1 = "Pass", otherwise
0
Bit 17 1 if partial result 1 = "Fail", otherwise
0
Bit 18 1 if partial result 2 = "Pass", otherwise
0
Bit 19 1 if partial result 2 = "Fail", otherwise
0
Bit 20 1 if partial result 3 = "Pass", otherwise
0
Bit 21 1 if partial result 3 = "Fail", otherwise
0
Bit 22 1 if partial result 4 = "Pass", otherwise
0
Bit 23 1 if partial result 4 = "Fail", otherwise
0
Bit 24 1 if partial result 5 = "Pass", otherwise
0
Bit 25 1 if partial result 5 = "Fail", otherwise
0
