12.3.11 Pattern comparison

This feature check verifies the presence of a taught-in pattern.
It supports external teach. The current image area is adopted in the model, but the switching points remain
unchanged.
Proceed as follows for configuration:

The field of view must firstly be defined.

Teach in a new pattern using this button.
