13.6 Job selection via digital inputs

There are two ways of switching the active job of the device via the digital inputs:

Binary: Bit serial: The stored jobs can be selected directly using a clock and data line.

Bit serial: The stored jobs can be selected directly using a clock and data line.
Switching between jobs is only possible when the current mode is set to Activated. Switching between jobs is
not possible in any other modes. Observe that you must activate the option Job selection via digital inputs in
the Job Management to execute job selection by this means.
You can also switch the active job by transferring corresponding Commands via the process interface.
