4.10.4 Light Beacon

Perform the following procedures to check function of the Light Beacon.
To test the Light Beacon:
1. Close the dispensing system hood, make sure the EMO is deactivated, and press the green
( ) button on the front panel.
ON l
The green beacon light should be ON.
2. Open the hood.
The yellow beacon light should come ON and the green beacon light should go OFF.
3. Close the dispensing system hood.
The green beacon light should come ON and the yellow beacon light should go OFF.
4. In the FmXP Main Window, click on
5. In the Tools Window, click on
6. Click on
Dispenser.
The I/O Test Dialog screen opens.
7. Locate the tab (Figure 4-10) with the beacon color outputs (
8. Make sure the
9. Toggle the button next to the desired output
10. Click on
OK
11. Click on
Main
4-14
I/O Test
SOFTWARE_ACTIVE

Figure 4-10 Dispenser I/O (Outputs 32-63)

to return to the Tools Window.
to return to the Main Window.
.
Tools
.
BEACON_YELLOW
bit is ( ). If not, the beacon lights will not toggle.
ON l
( ) and (
ON l OFF 0
, etc.).
) to test the beacon signal.
