Opening A New Program Window - Nordson Asymtek Spectrum Series Installation, Operation & Maintenance Manual

2. Indicate the number of fiducials to be used in your program.
If
No Fiducials
when opening an existing program. To activate this feature, make sure there is a
checkmark in the textbox next to
•
All dispensing locations on the workpiece are defined in reference to the
workpiece origin.
•
The workpiece origin is defined as the point where the position counters are reset to
(x0, y0) or (0, 0).
3. Click .
OK
6.9.5

Opening a New Program Window

To create a new program:
1. Select
Teach a Program
The Programming Window opens.
The last saved program opens when you start FmXP.
2. To create a new program, select
icon on the toolbar.
Wizard
This action clears the work area, loads the default fluid and heater files, and opens the
Create Workpiece Window (Figure 6-19).
You will be prompted to define the number of fiducials and skip marks.
3. Enter the desired information and click
You will be prompted to teach the workpiece origin and fiducial locations, if applicable.
6-24
is selected, you have the option of confirming the workpiece origin
Confirm Origin location ...
from the Main Menu.
from the menu bar or click on the
File > New
Figure 6-19 Create Workpiece
OK.
Program
Operation
