4.10.9 Tactile Sensor

Perform the following procedures to make sure that the Tactile Sensor is functioning properly.
NOTE The following procedure assumes the dispensing system is on and FmXP is running.
1. Verify your dispensing system has been configured for the type of Needle Sensor installed
as follows:
a. In the FmXP main Window, click on
Offsets Parameters
b. In the Machine Offsets Parameters dialog box (Figure 4-19), verify the sensor type
installed on your system.
If necessary, click on the arrow
sensor type.
c. Click on
2. In the FmXP Main Window, click on
3. In the Tools Window, click on
4-30
.
to return to the Main Window.
OK
Figure 4-19 Machine Offsets Parameters Dialog Box
I/O Test
Configuration > Machine Offsets > Machine
in the Sensor Type box and select the correct
.
Tools
and then on
Dispenser .
Power-Up and Testing
