If a bit does not toggle ON and OFF check the following:
- Board Sensor connections.
- Sensitivity of the Board Sensor. See
If the bit still does not toggle, refer to
To check Lift Table operation:
NOTE
This procedure assumes that the dispensing system hood is open and the FmXP
Conveyer I/O Test Dialog Box is open.
1. Check under and around all lift tables and heater tooling to make sure that no electrical or
pneumatic lines are in danger of being pinched or snagged.
2. Make sure that no electrical or pneumatic lines are touching the scale or scale base.
3. Manually place production sample workpieces on the conveyor in the pre-dispense, dispense,
and post-dispense stations, as applicable to your dispensing system configuration.
4. In the Conveyor Test I/O dialog box (Figure 4-13), locate the Lifter output buttons
(
Lift_Up_Left, Lift_Up_Ctr
5. Raise the lift table by toggling the output buttons
6. Lower the lift table by toggling the output buttons
7. Repeat Steps 4 through 6 for the pre-dispense station and the post-dispense station lift tables,
if applicable.
The lift tables should raise and lower smoothly and no parts should shift during the lifting
and lowering process.
If the lift tables do not operate as specified, the air pressure may need to be adjusted as
specified in
If air adjustment does not remedy the problem, refer to
To check Stop Pin operation:
NOTE
This procedure assumes that the dispensing system hood is open and FmXP Conveyer
I/O Test Dialog Box is open.
1. Locate the stop pin output buttons (
2. Raise and lower the stop pins by toggling the stop pin buttons
The stop pins should raise and lower smoothly.
3. If the stop pins do not operate as specified, refer to
Power-Up and Testing
, etc.).
Section 5 - Calibration and
Stop_Hold_Left, Stop_Hold_Ctr
5.11 Adjusting the Board
Section 8 - Troubleshooting.
ON ( 1 ).
( ).
OFF 0
Adjustment.
Section 8 -
ON
Section 8 - Troubleshooting.
Sensors.
Troubleshooting.
, etc.).
( ) and ( ).
1 OFF 0
