5. Remove the tape covering the Service Station.
6. Remove the front cover by first removing the two screws from the ends of the cover. See
Figure 3-6.
7. Lift the cover up and away from the machine.
CAUTION!
3-6

Figure 3-5 Removing the Service Station Packing Tape

The scale stem is extremely sensitive. Hitting or applying pressure to the scale
stem may damage the scale stem. See Figure 3-7.

Figure 3-6 Removing the Front Cover

Installation
