Figure 3-3 Dispensing Head Stopper Locations; Figure 3-4 Removing The Z-Head Bracket - Nordson Asymtek Spectrum Series Installation, Operation & Maintenance Manual

Item
1 Y-Axis Stopper
2 Y-Rail (right side)
4. Remove the shipping bracket and warning tag attached to the Z-Head by loosening the
screws. See Figure 3-4.
Retain bracket and hardware for future shipping purposes.
Item
1 Allen Head Screws
Installation
1
Description

Figure 3-3 Dispensing Head Stopper Locations

Figure 3-4 Removing the Z-Head Bracket

2
Item
3 X-Axis Stopper
4 X-Beam
Description
3
Description
1
4
3-5
