Software Controlled Light Beacon - Nordson Asymtek Spectrum Series Installation, Operation & Maintenance Manual

5.13 Software Controlled Light Beacon

Beacon Configuration allows you to easily configure beacon and audible alarm states for various
FmXP/dispensing system operational conditions.
To configure the desired beacon state and audible alarm:
1. In the Main Window, select
.
Control
The Beacon Configuration dialog box (Figure 5-16) opens.
NOTE Click on the desired tab to select one of the following categories: See Figure 5-17.
Error Conditions
Program States – 1
Program States – 2
FmXP States
5-14
Configuration > Setup Runtime Preferences > Beacon
Figure 5-16 Beacon Configuration Dialog Box
Calibration and Adjustment
