3.8

Leveling the Scale

1. Check the scale level bubble.
If the bubble is not centered, the scale must be leveled. If the bubble is centered, the scale
is level.
2. Adjust the scale leveling screws until the scale is level (Figure 3-11).
Leveling Screws
3. Replace the scale cover and reinstall the two mounting screws (Figure 3-12).
3-10

Figure 3-11 Leveling the Scale

Figure 3-12 Replacing the Scale Cover

Bubble
Installation
