8.4.11.1 Tactile Sensor Error
If you receive a tactile sensor error, the following procedure may remedy the error.
NOTE If you continue to receive tactile sensor errors after performing the following procedure,
contact Asymtek Technical Support.
1. Gently lift the cap off of the tactile sensor as shown in Figure 8-5.
2. Use isopropyl alcohol and a soft cloth to remove any residual fluid from around the
circumference of the cap and around the tactile sensor opening. Carefully remove any
residual fluid from the sensor tip as well.
3. Replace the cap.
4. In the Main Window, click on
5. In the Tools Window, click on
6. Click on
Dispenser
7. Locate the I/O for the tactile sensor.
8. Gently press down on the tactile sensor and make sure that the bit toggles
If the bit does not toggle
Asymtek Technical Support.
Item
1 Tactile Sensor Cap
2 Tactile Sensor
Troubleshooting
.
Tools
.
I/O Test
.
and
ON OFF
1
2
Description
Figure 8-5 Tactile Sensor Exposed
, the tactile sensor may need to be replaced. Contact
and .
ON OFF
8-13
