10.3 Specifications

Dispensing Area
Motion System
Vision and Lighting
Conveyor
Service Station
Heaters
Height Sensor
Computer
Software
Fluid Delivery Method
Energy Consumption
AIC Interrupt Capacity
Audible Noise Level
Ionizing and Non-ionizing
Radiation
Contaminants
Residual Risks of
Materials Used to
Construct Equipment
10-2

Table 10-3 Specifications

Specifications
Single Dispense Head: 340 mm x 415 mm [13.4 in. x 16.3 in.]
Z-Travel: 60 mm
Z-Axis Payload: 3 kg
Type: Brushless DC servo motors, closed-loop encoder feedback
X-Y Velocity: 1000 mm/s maximum
Z-Axis Velocity: 500 mm/s maximum
X-Y Repeatability: ±0.025 mm (0.001 in.)
Z-Axis Repeatability: ±0.025 mm (0.001 in.)
X-Y-Z Resolution: 0.005 mm (0.0002 in.)
Positional Accuracy: ±0.050 mm (0.002 in.)
Vision system with Automatic Pattern Recognition
Image size: 6.35 mm (0.25 in.) standard
Lighting: Programmable, red/blue LED, 256 steps
SMEMA Compliant
Single or Dual Lane Configuration
Flat Belt
Motorized Rail Spacing
1 Dispensing Station standard, 3 Dispensing Stations available
Fiber-optic over-the-rail board sensors at all stations
Over-the-rail stop pins
Needle Vacuum Purge Cup
On-Board High Precision Scale
Needle Calibration Substrate
120°C, ± 5°C for impingement heaters
Standard: Integral Mechanical Height Sensor
Optional: Laser
Windows-based Laptop PC with DVD-RW drive
User interface: Color LCD flat-panel display; ASCII keyboard & touchpad;
Ethernet network port, left and right USB ports
User Environment: Fluidmove for Windows XP
Operating System: Windows XP
DispenseJet DJ-9000; DJ-2200, Heli-flow DV-7000 and DV-8000 pumps;
DV-01, DV-02, DV-03, DV-05, DV-07, DV-09.
S-920 Idle: 550 W
S-920 Peak: 1000 W (Not including heaters)
S-922 Idle: 625 W
S-922 Peak: 1075 W (Not including heaters)
10kA
70 dBA, 76 db peak
N/A
N/A
None
