Replacing the Height Sensor Probe

To replace the Height Sensor Probe:
1. Remove all valve clamps attached to the Z-head (
2. Remove the Z-head top cover.
3. Remove the front valve panel.
4. Unhook the two springs from the upper spring bracket.
5. Remove the Z-plate.
6. Dismount the height sensor assembly from the Z-carriage.
1
2
F igure 9-4A Removing the Z-head Top Cover
1 7 H
and Front Valve Panel
Item
1 Z-head Cover and Front Valve Panel
2 Valve Clamps
3 Upper Bracket Springs
Parts Replacement
Description
Figure 9-4 Removing the Z-Head Panels
F igure 9-4).
1 6 H
3
4
F igure 9-4B Removing the Z-plate
1 8 H
Item Description
4 Z-plate
5 Height Sensor Assembly
6 Z-carriage
6
5
9-9
