Calibrating the Scale

Tools and Materials Needed:
•
Calibration Weight Set (P/N 193758)
•
Screwdriver
To calibrate the scale:
1. Remove the scale cover.
2. Verify that the scale is level by
checking the scale level bubble.
a. If the bubble is not centered, the
scale must be leveled.
b. If the bubble is centered, the
scale is level.
3. If necessary, adjust the scale leveling
screws until the scale is level
(Figure 5-6).
Leveling Screws
4. When finished, replace the scale cover.
5. Start FmXP.
6. Select
Configuration > Setup Scale
The Scale Setup Window (Figure 5-7) opens.
5-6
Figure 5-5 Scale Cover Removal
Figure 5-6 Leveling the Scale
from the Main Window.
•
Latex gloves or tweezers
•
Level
Calibration and Adjustment
Bubble
