4. Open the dispensing system hood and move the dispensing head to the front middle of the
dispensing area.
WARNING!
5. Wearing gloves, clean all accessible cables using a soft lint-free cloth and isopropyl alcohol.
WARNING!
6. Visually inspect the cleaned cables for uneven and excessive wear. Run a lint-free cloth over
cables while feeling for breaks in sheathing or swollen spots.
NOTE If the cables show signs of wear, skip this procedure and contact Asymtek. If the
7. Wearing rubber gloves, manually apply an adequate but not excessive amount of grease to
the exposed portion of all mechanical cables.
From the rear of the system, apply grease to the portions of cable wrapped around the
motor pulley as well as the cable lengths leading to the rest of the positioner.
From the front of the system, apply grease to the X and Y cables on the Motor Pulleys.
TIP
8. Manually move the dispensing head to the rear middle of the dispensing area and repeat
Steps 5-7.
9. When finished, replace the axis and cable covers.
7-10
Use Personal Protective Equipment when working with cleaning and lubrication
materials. Refer to the applicable MSDS. Remove all spills and properly dispose
of contaminated materials.
Fingers may be pinched if the dispensing head is moved while cleaning and
lubricating the cables.
cables show no signs of wear, proceed with the next step.
Moving the dispensing head in the X and Y direction while applying the grease
to the motor pulley simplifies this step.
Maintenance
