Front Cabinet; Figure 1-6 Front Cabinet (Dual Conveyor System Shown) - Nordson Asymtek Spectrum Series Installation, Operation & Maintenance Manual

1.10.4 Front Cabinet

7
6
Item Name
Fluid Vacuum
1
Suckback
Cooling/Coaxial Air
2
Regulator
Valve Pressure
3
Regulator
Fluid Pressure
4
Regulator
Conveyor/Heater
5
Modules
Impingement
6
Flowmeters
Tooling Air
7
Regulator
Introduction
2
1
Controls the vacuum level applied to fluid pressure air line when pressure
is turned off. The vacuum helps prevent residual pressure buildup in the
syringe that may cause fluid drip.
Controls the air pressure supplied to either the valve cooling air port or
the DJ-2200 coaxial air assist, depending on machine configuration.
Controls the air pressure supplied to the dispensing valve.
Controls the air pressure supplied to the fluid syringe.
Controls all conveyor functions (motors, sensors, pneumatics, etc.). It
receives power from the Power Manager and supplies AC power to the
substrate heaters in the dispensing area. If your system is equipped with
dual conveyors, two Conveyor/Heater Modules are required.
Control the airflow through the Impingement Heaters in the dispensing
chamber. A manual shut-off valve controls the air going to the flowmeters.
Controls the air pressure supplied to the stop pins and lift tables. The
regulator receives air from the main air regulator located on the back of
the dispensing system.

Figure 1-6 Front Cabinet (Dual Conveyor System shown)

4
3
5
Description
1-13
