6.8.2

Lighting and Color Adjustment

The light intensity and color level can be adjusted to optimize the view of your workpiece. See
Calibration and Adjustment
CAUTION!
To adjust lighting intensity and color level:
1. Open the hood, place a workpiece on the heated vacuum tooling plate, and close the hood.
2. Access the Jog Window using one of the following methods:
•
Select
Jog
•
Select the
•
Press
[Ctrl]+[J]
3. At the bottom of the Jog Controls, click on
click on
Reticles
4. In the Reticles Setup Window, use the Jog Controls to move the dispensing head over the
sample workpiece so that the video display reticles are aligned with a fiducial. See
Figure 6-14.
5. View the fiducial in the video display screen while adjusting the two lighting controls until
you get the highest contrast between the fiducial and substrate or between the part being
dispensed upon and the surrounding area.
6. Adjust the brightness and red/blue color balance by vertically moving the control slides on
the right side of the dialog box. Clicking on the light bulb icon
slide from a linked mode to an unlinked mode that permits up to 255 independent color
level/brightness levels.
NOTE For more information concerning fiducials and video display contrast, refer to the
Fluidmove User Guide or Online Help.
Operation
for instructions on focusing and calibrating the camera.
Except for lighting adjustments and lens replacement, all other configuration and
adjustments should only be performed by a trained service technician.
from the Main Menu.
button in the Production Window.
Jog
on the keyboard.
. See Figure 6-14.
and when the video display screen appears,
Video
Section 5 -
toggles the light control
6-17
