NPT-1020 Installation and Maintenance Manual

5.4.2 Installing the Rear Panel

D
ANGER: The operator is responsible for the secure mounting of the cabinet to the wall,
using appropriate installation materials.
N
OTE: Use only the self-tapping screws, supplied with the cabinet.
To install the rear panel:
1. Place the rear panel on the drilled holes and align it correctly so that it is flat. Place support beneath
as required.
2. Attach the panel to the wall and fasten with four screws.
ECI Telecom Ltd. Proprietary

Figure 5-5: Installing the rear panel

NPT-1020 Wall-Mounted Installations
5-5
