NPT-1020 Installation and Maintenance Manual
Table 8-21: ICP_VF RJ-45 connector, pin assignment for serving SM_CODIR_4E
Pin Name
RA
1
RB
2
TA
3
TB
4

8.15 ICP_V24 Connection Data

V.24 interfaces in the SM_V24E are always in DCE mode. One ICP_V24 can serve one SM_V24E module. The
SM_V24E module can work in the following three modes:
Eight channels of transparent without controls mode (Connectors marked SYNC CH1 and SYNC CH2

are not connected.)
Four channels of asynchronous with controls mode (Connectors marked SYNC CH1 and SYNC CH2 and

CH5 to CH8 are not connected.)
Two channels of synchronous with controls mode (Connectors marked CH1 to CH8 are not

connected.)
Two types of connectors for external interfaces are on the front panel of the ICP_V24:
25-pin D-type male connector for synchronous V.24 interfaces

9-pin D-type male connector for transparent or asynchronous V.24 interfaces

The following figure identifies the 25-pin D-type male connector pins as seen when looking into the
connector. The table lists the connector pin assignment for a typical connector and the color of the wire
connected to the corresponding pin in the cables offered by ECI for connecting the tributary connector and
a distribution frame.
Table 8-22: ICP_V24 synchronous V.24 25-pin D-type connector, pin assignment
Pin Name
1 ---
2 SD (103)
3 RD (104)
4 RTS (105)
5 CTS (106)
6 DSR (107)
7 GND
8 DCD (109)
ECI Telecom Ltd. Proprietary
Function Direction
Rx, wire A Input
Rx, wire B Input
Tx, wire A Output
Tx, wire B Output
Figure 8-11: 25-pin D-type male connector, pin identification
Function
Not connected
Transmit data
Receive data
Request to send
Clear to send
Data set ready
Signal ground
Data carrier detect
Wire color
Blue/White ring
White/Blue ring
Green/White ring
White/Green ring
Direction Wire color
--- ---
Input Brown
Output Brown/Gray-ring
Input Red
Output Red/Gray-ring
Output Orange
--- Orange/Gray-ring
Output Yellow
Connection Data
