5.18.6 Connecting Timing (Clock) Cables

Timing cables are connected to the T3/T4 connectors of the NPT-1020.
To connect a timing cable to the NPT-1020 platform:
1. Route the timing cable along the side of the frame. Fasten the cable to the cable supports, using cable
ties.
2. Pull the cable down to the level of the T3/T4 connectors and bend it until the cable connector is
positioned against the timing connector.
3. Connect the free end of the cable in accordance with the frame installation plan and the cable tags to
connector T3/T4 on the platform.
4. Use cable ties as required to fasten the cable to the frame cable supports.

5.18.7 Connecting Management Cables

The management cables are connected to the RJ-45 connectors designated MNG on the NPT-1020
platform. Each cable is terminated in an RJ-45 plug.
To connect management cables to the NPT-1020 platform:
1. Bring the cable plug against the appropriate connector on the NPT-1020.
2. Connect the management station cable to the MNG connector of the platform in accordance with the
frame installation plan and the cable tags.
3. Bend the cable and thread it through the space above the NPT-1020 and the left side of the frame.
4. Use cable ties as required to fasten the cable to the frame cable supports.
