9.1.2 Installing the Rack on Concrete Floors

To install the rack on a concrete floor:
1. Drill the required mounting holes in accordance with the appropriate template. See diagram a. in the
figure "Mounting diagrams for ETSI racks", and diagram a. or b. in the figure "Mounting diagrams for
19" and 23" racks"
2. Insert expansion shields into the holes.
3. Position the rack over the mounting holes.
4. Secure the rack to the floor with the bolts supplied in the mounting kit, in accordance with diagram b.
or diagram c. in the figure "Mounting diagrams for 19" and 23" racks"
Floors).

9.1.3 Installing the Rack on Wooden Floors

To install the rack on a wooden floor:
1. Drill the required mounting holes in accordance with the appropriate template (see the following
figures), using a 5 mm drill bit.
2. Position the rack over the mounting holes.
3. Secure the rack to the floor using the appropriate wood screws (see the following figures).
ECI Telecom Ltd. Proprietary
(Rack Installation on Wooden Floors).
Rack Installation
(Rack Installation on Wooden
