NPT-1020 Installation and Maintenance Manual
P2 pin Name
TRING11
3
---
4
---
5
TTIP10
6
TRING10
7
TTIP9
8
TRING9
9
---
10
---
11
TRING8
12
TTIP8
13
TTIP7
14
TRING7
15
---
16
---
17
TTIP6
18
TRING6
19
TTIP5
20
TRING5
21
---
22
---
23
TTIP4
24
TRING4
25
TTIP3
26
TRING3
27
---
28
---
29
TTIP2
30
ECI Telecom Ltd. Proprietary
Function
Transmit, tributary 11, wire B
Not connected
Not connected
Transmit, tributary 10, wire A
Transmit, tributary 10, wire B
Transmit, tributary 9, wire A
Transmit, tributary 9, wire B
Not connected
Not connected
Transmit, tributary 8, wire B
Transmit, tributary 8, wire A
Transmit, tributary 7, wire A
Transmit, tributary 7, wire B
Not connected
Not connected
Transmit, tributary 6, wire A
Transmit, tributary 6, wire B
Transmit, tributary 5, wire A
Transmit, tributary 5, wire B
Not connected
Not connected
Transmit, tributary 4, wire A
Transmit, tributary 4, wire B
Transmit, tributary 3, wire A
Transmit, tributary 3, wire B
Not connected
Not connected
Transmit, tributary 2, wire A
Direction Wire color
Output Brown/Gray ring
--- ---
--- ---
Output Red
Output Red/Gray ring
Output Orange
Output Orange/Gray ring
--- ---
--- ---
Output Yellow
Output Yellow/Gray ring
Output Green
Output Green/Gray ring
--- ---
--- ---
Output Blue
Output Blue/Gray ring
Output Violet
Output Violet/Gray ring
--- ---
--- ---
Output White
Output White/Gray ring
Output Pink
Output Pink/Gray ring
--- ---
--- ---
Output Brown/White ring
Connection Data
8-16
