NPT-1020 Installation and Maintenance Manual
Pin Name
15 ---
16 ---
17 TMC+ (113a)
18 ---
19 GND (102)
20 ---
21 ---
22 TD- (103b)
23 TC- (114b)
24 RD- (104b)
25 RTS_O- (105b)
26 RC- (115b)
27 CTS- (106b)
28 ---
29 ---
30 ---
31 ---
32 ---
33 ---
34 ---
35 TMC- (113b)
36 ---
37 ---
Table 8-29: ICP_DB37D 37-pin D-type connector, RS-449 pin assignment
Pin Name
4 TD+ (103a)
6 RD+ (104a)
19 GND (102)
22 TD- (103b)
24 RD- (104b)
ECI Telecom Ltd. Proprietary
Function
Not connected
Not connected
Terminal timing+
Not connected
Signal ground
Not connected
Not connected
Transmit data-
Transmit timing-
Receive data-
Request to send-
Receive timing-
Clear to send-
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Terminal timing-
Not connected
Not connected
Function
Transmit data+
Receive data+
Signal ground
Transmit data-
Receive data-
Direction Wire color
--- ---
--- ---
--- Green
--- ---
--- Green/White
--- ---
--- ---
Output Blue
Output Blue/White
--- Purple
Input Purple/White
Input Gray
Output Gray/Black
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
Output White
--- ---
--- ---
Direction Wire color
Output Black/White
Input Brown/White
--- Green/White
Output Blue
--- Purple
Connection Data
8-39
