NPT-1020 Installation and Maintenance Manual
5.15.2 Installing the NPT-1020, a DDF, and a RAP-BG (Option
2)
To install the NPT-1020:
1. Identify the prescribed position of the NPT-1020 in the wall-mounted frame.
2. Attach the NPT-1020 to the frame with four M6 Phill. screws and flat washers.
3. Fasten the NPT-1020 to the frame.
To install the DDF:
1. Identify the prescribed position of the DDF in the wall-mounted frame.
2. Attach the DDF to the frame with four M6 Phill. screws and flat washers.
3. Fasten the DDF to the frame.
To install the RAP-BG:
1. Identify the prescribed position of the RAP-BG in the wall-mounted frame.
2. Attach the RAP-BG to the frame with four M6 Phill. screws and flat washers.
3. Fasten the RAP-BG to the frame.
5.15.3 Installing the NPT-1020, a DDF, and an AC/DC CONV
(Option 4)
To install the NPT-1020:
1. Identify the prescribed position of the NPT-1020 in the wall-mounted frame.
2. Attach the NPT-1020 to the frame with four M6 Phill. screws and flat washers.
3. Fasten the NPT-1020 to the frame.
To install the DDF:
1. Identify the prescribed position of the DDF in the wall-mounted frame.
2. Attach the DDF to the frame with four M6 Phill. screws and flat washers.
3. Fasten the DDF to the frame.
ECI Telecom Ltd. Proprietary
NPT-1020 Wall-Mounted Installations
5-34
