NPT-1020 Installation and Maintenance Manual
Assignment Pin Designation
61 ALMIN14
62 ALM_IN14
63 ALMIN15
64 ALM_IN15
65 ALMIN16
66 ALM_IN16
All platforms 67 WARN_NC
68 WARN_NO
ECI Telecom Ltd. Proprietary
Function
External alarm input 14
External alarm input 14
External alarm input 15
External alarm input 15
External alarm input 16
External alarm input 16
Warning alarm relay, normally closed contact
Warning alarm relay, normally open contact
Connection Data
Direction Wire color
Input White/Red dots
Input Pink/Red dots
Input Yellow/White
Input Gray/White
Input Pink/White
Input Brown/Black
Output Blue/Black
Output Gray/White dots
