NPT-1020 Installation and Maintenance Manual
Pin Name
64 RRING16
65 ---
66 RTIP15
67 RRING15
68 RTIP14
69 RRING14
70 RTIP13
71 RRING13
72 ---
73 RTIP12
74 RRING12
75 RTIP11
76 RRING11
77 RTIP10
78 RRING10
79 ---
80 RTIP9
81 RRING9
82 RTIP8
83 RRING8
84 RTIP7
85 RRING7
86 ---
87 RTIP6
88 RRING6
89 RTIP5
90 RRING5
91 RTIP4
92 RRING4
93 ---
94 RTIP3
95 RRING3
96 RTIP2
97 RRING2
98 RTIP1
99 RRING1
ECI Telecom Ltd. Proprietary
Function
Receive, tributary 16, wire B
Not connected
Receive, tributary 15, wire A
Receive, tributary 15, wire B
Receive, tributary 14, wire A
Receive, tributary 14, wire B
Receive, tributary 13, wire A
Receive, tributary 13, wire B
Not connected
Receive, tributary 12, wire A
Receive, tributary 12, wire B
Receive, tributary 11, wire A
Receive, tributary 11, wire B
Receive, tributary 10, wire A
Receive, tributary 10, wire B
Not connected
Receive, tributary 9, wire A
Receive, tributary 9, wire B
Receive, tributary 8, wire A
Receive, tributary 8, wire B
Receive, tributary 7, wire A
Receive, tributary 7, wire B
Not connected
Receive, tributary 6, wire A
Receive, tributary 6, wire B
Receive, tributary 5, wire A
Receive, tributary 5, wire B
Receive, tributary 4, wire A
Receive, tributary 4, wire B
Not connected
Receive, tributary 3, wire A
Receive, tributary 3, wire B
Receive, tributary 2, wire A
Receive, tributary 2, wire B
Receive, tributary 1, wire A
Receive, tributary 1, wire B
Direction Wire color
Input Brown/Blue ring
--- ---
Input White/Yellow ring
Input Light Gray/Yellow ring
Input Violet/Yellow ring
Input Blue/Yellow ring
Input Green/Yellow ring
Input Orange/Yellow ring
--- ---
Input Red/Yellow ring
Input Brown/Yellow ring
Input Blue/White ring
Input Green/White ring
Input Light Gray/White ring
Input Violet/White ring
--- ---
Input Yellow/Brown ring
Input Red/Brown ring
Input Green/Brown ring
Input Orange/Brown ring
Input Violet/Brown ring
Input Blue/Brown ring
--- ---
Input Pink/Brown ring
Input Light Gray/Brown ring
Input Light Gray/Red ring
Input Brown/Red ring
Input Green/Red ring
Input Yellow/Red ring
--- ---
Input Violet/Red ring
Input Blue/Red ring
Input Pink/Red ring
Input White/Red ring
Input Light Gray/Green ring
Input Brown/Green ring
Connection Data
8-13
