NPT-1020 Installation and Maintenance Manual
P2 pin Name
---
44
---
45
RRING8
46
RTIP8
47
RRING7
48
RTIP7
49
---
50
---
51
RTIP6
52
RRING6
53
RTIP5
54
RRING5
55
---
56
---
57
RTIP4
58
RRING4
59
RTIP3
60
RRING3
61
---
62
---
63
RTIP2
64
RRING2
65
RTIP1
66
RRING1
67
---
68
---
Shelf
ECI Telecom Ltd. Proprietary
Function
Not connected
Not connected
Receive, tributary 8, wire B
Receive, tributary 8, wire A
Receive, tributary 7, wire B
Receive, tributary 7, wire A
Not connected
Not connected
Receive, tributary 6, wire A
Receive, tributary 6, wire B
Receive, tributary 5, wire A
Receive, tributary 5, wire B
Not connected
Not connected
Receive, tributary 4, wire A
Receive, tributary 4, wire B
Receive, tributary 3, wire A
Receive, tributary 3, wire B
Not connected
Not connected
Receive, tributary 2, wire A
Receive, tributary 2, wire B
Receive, tributary 1, wire A
Receive, tributary 1, wire B
Not connected
BRAID
Direction Wire color
--- ---
--- ---
Input Orange/Brown ring
Input Green/Brown ring
Input Blue/Brown ring
Input Violet/Brown ring
--- ---
--- ---
Input Light Gray/Brown ring
Input Pink/Brown ring
Input Brown/Red ring
Input Light Gray/Red ring
--- ---
--- ---
Input Yellow/Red ring
Input Green/Red ring
Input Blue/Red ring
Input Violet/Red ring
--- ---
--- ---
Input White/Red ring
Input Pink/Red ring
Input Brown/Green ring
Input Light Gray/Green ring
--- ---
--- ---
Connection Data
8-7
