NPT-1020 Installation and Maintenance Manual

Table 3-3: Equipment dimensions

Equipment type
NPT-1020
EXT-2U
RAP-BG
RAP-4B
FST
ODF
xDDF-21
ICP_MCP30

3.2.3 Power Sources

NPT-1020 platforms can be powered by DC sources complying with the applicable sections of ETSI 300
132-2 and the SELV or TNV requirements of EN 60950. The nominal supply voltage is -48 VDC (positive-lead
grounded). However, the allowed supply voltage range is -40.5 VDC to -60 VDC. Two separate DC power
sources must be available for redundancy. In the DC power supply, the maximum power consumption of
the NPT-1020 is 55 W.
For AC power supply, configure an external AC/DC converter.
N
OTE: If the planned power consumption of the equipment installed in the platform is 80% or
more of the maximum listed value, it is recommended to consult ECI Customer Support.
3.3

Tools and Test Equipment

No special-purpose tools beyond a standard technician's toolbox are required for the installation of
NPT-1020 platforms.
Traffic cables can be prepared on site, so make sure suitable tool kits are available. They include tools for
the assembly of coaxial cables as listed in the following table, and tools for the preparation of optical patch
cords.

Table 3-4: Recommended coaxial cable assembly tools

No. Name
Stripper
1
Center contact crimp tool (blue)
2
Crimp tool, outer
3
Cable stripper
4
ECI Telecom Ltd. Proprietary
Height (mm) Width (mm)
44 440
88.9 443.4
88 440
88 447
44.5 440
44.5 440
44.5 440
44 440
Depth (mm) Max. weight (kg)
243 5
243 4.5
150 4
155 2.4
240 5
240 8
150 1.5
140 1.5
Description
DIN 1.0/2.3
DIN 1.0/2.3
DIN 1.0/2.3
---
Before You Start
3-4
