NPT-1020 Installation and Maintenance Manual
To install the AC/DC CONV:
1. Identify the prescribed position of the AC/DC CONV in the wall-mounted frame.
2. Attach the AC/DC CONV to the frame with four M6 Phill. screws and flat washers.
3. Fasten the AC/DC CONV to the frame.

5.15.4 Installing the NPT-1020 and a DDF (Option 5)

To install the NPT-1020:
1. Identify the prescribed position of the NPT-1020 in the wall-mounted frame.
2. Attach the NPT-1020 to the frame with four M6 Phill. screws and flat washers.
3. Fasten the NPT-1020 to the frame.
To install the DDF:
1. Identify the prescribed position of the DDF in the wall-mounted frame.
2. Attach the DDF to the frame with four M6 Phill. screws and flat washers.
3. Fasten the DDF to the frame.
5.16 Installing the Wall-Mounted Frame Front
Cover
The transparent cover protects the NPT-1020 traffic and fiber cables against unintended disconnection or
bending. The cover is attached to four holders on the frame's front side.
The installation of the cover includes the following steps:
1. Installing the cover holders
2. Attaching the transparent cover
