NPT-1020 Installation and Maintenance Manual
Pin
Name
5
CH1# DCD(109)
6
CH1# RC(115)
7
CH2# RTS(105)
8
CH2# CTS(106)
9
CH2# DTR(108)
10
CH2# DSR(107)
11
CH2# DCD(109)
12
CH2# RC(115)
13-18
---
19
CH1# SD(103)
20
CH1# RD(104)
21
CH2# SD(103)
22
CH2# RD(104)
23
CH1# TMC(113)
24
CH1# TC(114)
25
CH2# TMC(113)
26
CH2# TC(114)
27-34
---
35
SG1
36
SG2

8.13.4 Connection Data for SM_V35_V11 Interfaces

The SM_V35_V11 supports two channels of V.35 or V.11 interface. Each interface can independently be
configured as V.35 or V.11/X.24 and can be mapped to unframed E1 or N x 64K of framed E1 (the interface
rate N is configurable). The following table lists the pin assignment of V.11 interfaces for a typical connector
and the color of the wire connected to the corresponding pin in the cables offered by ECI for connecting the
tributary connector and a distribution frame.
Table 8-15: SM_10E/EM_10E SM_V35_V11 connector, pin assignment
Pin
V.11 signal
20
T(a)
19
T(b)
2
R(a)
1
R(b)
22
S(a)
21
S(b)
ECI Telecom Ltd. Proprietary
Function
Ch1# data carrier detect
Ch1# receive timing
Ch2# require to send
Ch2# clear to send
Ch2# data terminal ready
Ch2# data set ready
Ch2# data carrier detect
Ch2# receive timing
Not connected
CH1# transmit data
CH1# receive data
CH2# transmit data
CH2# receive data
Ch1# DTE timing
Ch1# transmit timing
Ch2# DTE timing
Ch2# transmit timing
Not connected
Signal ground
Signal ground
Function
Ch1# transmit data+
Ch1# transmit data-
Ch1# receive data+
Ch1# receive data-
Ch1# transmit timing+
Ch1# transmit timing-
Direction
Wire color
Output
Orange
Output
Orange/Black
Input
Yellow
Output
Yellow/Black
Input
Green
Output
Green/Black
Output
Blue
Output
Blue/Black
---
---
Brown/White
Output
Red/White
Input
Orange/White
Output
Yellow/White
Input
Green/White
Output
Blue/White
Input
Violet/White
Output
Light Gray/White
---
---
---
Brown/Red
---
Light Gray/Red
Direction
Wire color
Input
Red/White
Input
Brown/White
Output
Brown/Black
Output
Brown
Output
Yellow/White
Output
Orange/White
Connection Data
8-27
