NPT-1020 Installation and Maintenance Manual
Module Parameter
Source type
Minimum mean launched
power (dBm)
Maximum mean launched
power (dBm)

Table 3-13: LC transceivers laser information GbE SFP (OTGBE)

Module Parameter
GbE SFP Laser designation
Operating
wavelength (nm)
Source type
Minimum mean launched power
(dBm)
Maximum mean launched power
(dBm)
3.7

Protection against Electrostatic Discharge

This section provides guidelines regarding the protection of NPT-1020 equipment and its components
against electrostatic discharge (ESD) during handling, packing/unpacking, transport, installation,
commissioning, inspections, servicing, and maintenance.
Electronic equipment, assemblies, and components that are ESDS (electrostatic discharge sensitive) or
include sensitive items are identified by the basic ESD warning symbol shown in the following figure.
The information provided in this section is in line with CENELEC Electronic Components Committee (CECC)
specification CECC 00 015, which deals with protection of devices sensitive to ESD.
Most types of electronic equipment, assemblies, and components can be damaged by electrostatic
discharges. An ESD between two objects occurs when an object carrying static electrical charges touches or
is brought near another object.
ECI Telecom Ltd. Proprietary
Data
Single mode Single
-15
-8
Data
SX
850
Multi-mode
-9.5
-3

Figure 3-3: Basic ESD warning symbol

Single
mode mode
-5 -5
0 0
LX
1310
Single mode
-11
-3
Before You Start
Single Single
mode mode
-14 -14
-8 -8
EX
1550
Single mode
0
5
3-17
