NPT-1020 Installation and Maintenance Manual
Pin Name
6 RB3
7 RA4
8 RB4
9 RA5
10 RB5
11 RA6
12 RB6
13 E1
14 M1
15 E2
16 M2
17 E3
18 M3
19 TA1
20 TB1
21 TA2
22 TB2
23 TA3
24 TB3
25 TA4
26 TB4
ECI Telecom Ltd. Proprietary
Mode Function
4W Channel 3, Rx, wire B
2W Channel 3, wire B
4W Channel 4, Rx, wire A
2W Channel 4, wire A
4W Channel 4, Rx, wire B
2W Channel 4, wire B
4W Channel 5, Rx, wire A
2W Channel 5, wire A
4W Channel 5, Rx, wire B
2W Channel 5, wire B
4W Channel 6, Rx, wire A
2W Channel 6, wire A
4W Channel 6, Rx, wire B
2W Channel 6, wire B
Any Channel 1, E
Any Channel 1, M
Any Channel 2, E
Any Channel 2, M
Any Channel 3, E
Any Channel 3, M
4W Channel 1, Tx, wire A
2W ---
4W Channel 1, Tx, wire B
2W ---
4W Channel 2, Tx, wire A
2W ---
4W Channel 2, Tx, wire B
2W ---
4W Channel 3, Tx, wire A
2W ---
4W Channel 3, Tx, wire B
2W ---
4W Channel 4, Tx, wire A
2W ---
4W Channel 4, Tx, wire B
2W ---
Direction Wire color
Output Orange/Black
Bidirectional
Output Yellow
Bidirectional
Output Yellow/Black
Bidirectional
Output Green
Bidirectional
Output Green/Black
Bidirectional
Output Blue
Bidirectional
Output Blue/Black
Bidirectional
Output Violet
Input Violet/Black
Output White
Input White/Black
Output Pink
Input Pink/Black
Input Brown/White
---
Input Red/White
---
Input Orange/White
---
Input Yellow/White
---
Input Green/White
---
Input Blue/White
---
Input Violet/White
---
Input Light Gray/White
---
Connection Data
