Table 8-30: ICP_DB37D 37-pin D-type connector, RS-422 pin assignment
Pin Name
4 TD+ (103a)
6 RD+ (104a)
19 GND (102)
22 TD- (103b)
24 RD- (104b)
Table 8-31: ICP_DB37D 37-pin D-type connector, V.36 pin assignment
Pin Name
1 CGND
4 TD+ (103a)
5 TC+ (114a)
6 RD+ (104a)
7 RTS_O+ (105a)
8 RC+ (115a)
9 CTS_O+
11 DSR (107)
12 DTR (108)
13 DCD (109)
17 TMC+ (113a)
19 GND (102)
22 TD- (103b)
23 TC- (114b)
24 RD- (104b)
26 RC- (115b)
35 TMC- (113b)
Table 8-32: ICP_DB37D 37-pin D-type connector, V.35 pin assignment
Pin Name
1 CGND
4 TD+ (103a)
5 TC+ (114a)
6 RD+ (104a)
7 RTS_O+ (105a)
ECI Telecom Ltd. Proprietary
Function
Transmit data+
Receive data+
Signal ground
Transmit data-
Receive data-
Function
Case ground
Transmit data+
Transmit timing+
Receive data+
Request to send+
Receive timing+
Clear to send+
Data set ready
Data terminal ready
Data carrier detect
Terminal timing+
Signal ground
Transmit data-
Transmit timing-
Receive data-
Receive timing-
Terminal timing-
Function
Case ground
Transmit data+
Transmit timing+
Receive data+
Request to send+
Direction Wire color
Output Black/White
Input Brown/White
--- Green/White
Output Blue
--- Purple
Direction Wire color
--- Black
Output Black/White
Output Brown
Input Brown/White
Input Red
Input Red/White
Output Orange
Output Orange/White
Input Yellow
Output Yellow/Black
--- Green
--- Green/White
Output Blue
Output Blue/White
--- Purple
Input Gray
Output White
Direction Wire color
--- Black
Output Black/White
Output Brown
Input Brown/White
Input Red
