3.5.6 TOD/1PPS Cable

The NPT-1020 platform uses an RJ-45 connector on its front panel, marked TOD/1PPS, which provides
timing and synchronization input/output signals, supporting IEEE 1588v2 standard.
If it has balanced (120 Ω) G.703 interfaces, a multi twisted-pair cable with an RJ-45 connector (supplied by
ECI) is used to connect timing signals from the NPT-1020 to the site timing reference distribution
subsystems.
If the site timing reference distribution subsystem has unbalanced (75 Ω) G.703 interfaces, configure an
adapter with coaxial cables that provides balanced-to-unbalanced conversion (supplied by ECI).

3.5.7 Electric Traffic Cables

Some electric traffic cables can be prepared on site. The following table lists the type of cables and mating
connectors needed for each NPT-1020 traffic interface type.

Table 3-5: Traffic cables mating connector data for NPT-1020

Module or card Interface type
NPT-1020 E1 balanced (2.048
Mbps)
NPT-1020 10/100/1000BaseT
MSE1_16 E1 balanced (2.048
Mbps
PME1_21 E1 balanced (2.048
Mbps)
1
PME1_21 E1 balanced (2.048
Mbps)
PME1_63 E1 balanced (2.048
Mbps
xDDF-21 E1 unbalanced (2.048
Mbps)
PM345_3 E3/DS-3 (34/45 Mbps)
2
SMD1B STM-1 electrical
DHGE_8 10/100/1000BaseT
DHGE_4E 10/100/1000BaseT
1
Cable is used to connect the PME1_21 E1 interface connector to the xDDF-21.
2
Electrical or optical SFPs can be used when working in STM-1; the cable type is determined according to the SFP used.
ECI Telecom Ltd. Proprietary
Cable type Mating connector
Multipair cable (2 x 2 x 50-pin SCSI male
21 120 Ω twisted
pairs)
Cat5e RJ-45
Multipair cable (2 x 100-pin SCSI male
21 120 W twisted
pairs)
Multipair cable (2 x 100-pin SCSI male
21 120 Ω twisted
pairs)
Twin multipair cable 100-pin SCSI male
(2 x 21 120 Ω twisted
pairs)
3 x twin multipair 2 x 136-pin VHDCI
cable (2 x 21 120 Ω
twisted pairs)
Coaxial cable DIN 1.0/2.3
Coaxial cable DIN 1.0/2.3
Coaxial cable DIN 1.0/2.3 (on electrical
SFP)
Cat5e RJ-45
Cat5e RJ-45
Before You Start
Connector at other Qty./Module
end
Open
RJ-45
Open
Open
2 x 50-pin SCSI male
Open (connects to
DDF)
Open (prepared in
the field)
Open (prepared in
the field)
Open (prepared in
the field)
RJ-45
RJ-45
1
8
1
1
1
1
42
6
2/4
4
4
3-10
