NPT-1020 Installation and Maintenance Manual
P1 pin Name
RTIP20
27
RRING21
28
RTIP21
29
---
30
---
31
---
32
---
33
---
34
---
35
TRING12
36
TTIP12
37
TRING13
38
TTIP13
39
---
40
---
41
TRING14
42
TTIP14
43
TRING15
44
TTIP15
45
---
46
---
47
TTIP16
48
TRING16
49
TRING17
50
TTIP17
51
---
52
---
53
ECI Telecom Ltd. Proprietary
Function
Receive, tributary 20, wire A
Receive, tributary 21, wire B
Receive, tributary 21, wire A
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Transmit, tributary 12, wire B
Transmit, tributary 12, wire A
Transmit, tributary 13, wire B
Transmit, tributary 13, wire A
Not connected
Not connected
Transmit, tributary 14, wire B
Transmit, tributary 14, wire A
Transmit, tributary 15, wire B
Transmit, tributary 15, wire A
Not connected
Not connected
Transmit, tributary 16, wire A
Transmit, tributary 16, wire B
Transmit, tributary 17, wire B
Transmit, tributary 17, wire A
Not connected
Not connected
Direction Wire color
Input Red/Orange ring
Input Yellow/Orange ring
Input Green/Orange ring
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
Output Blue/Orange ring
Output Violet/Orange ring
Output Light Gray/Orange
ring
Output White/Orange ring
--- ---
--- ---
Output Brown/Violet ring
Output Red/Violet ring
Output Orange/Violet ring
Output Yellow/Violet ring
--- ---
--- ---
Output Green/Violet ring
Output Blue/Violet ring
Output Light Gray/Violet ring
Output White/Violet ring
--- ---
--- ---
Connection Data
8-9
