8.13.3 Connection Data for SM_V24E Interfaces

The SM_V24E module supports the following three modes:
8 x V.24 transparent without control signals

4 x V.24 asynchronous mode with control signals

2 x V.24 synchronous mode with control signals

In 8 x V.24 transparent mode, the SM_V24E supports eight channels, each with three wires. The following
table lists the pin assignment for a typical connector when the SM_V24E is in 8 x V.24 transparent mode.
This table also lists the color of the wire connected to the corresponding pin in the cables offered by ECI for
connecting the tributary connector and a distribution frame.
Table 8-12: SM_10E/EM_10E SM_V24E connector, pin assignment for 8 x V.24 transparent without
controls mode
Pin Name
13 CH7# SD(103)
14 CH7# RD(104)
15 CH8# SD(103)
16 CH8# RD(104)
17 GND
18 GND
19 CH1# SD(103)
