NPT-1020 Installation and Maintenance Manual
P1 pin Name
TRING18
54
TTIP18
55
TRING19
56
TTIP19
57
---
58
---
59
TRING20
60
TTIP20
61
TRING21
62
TTIP21
63
---
64
---
65
---
66
---
67
---
68
---
Shelf
8.8

E1 Connectors on the PME1_21 and MSE1_16

The PME1_21 provides 21 balanced E1 tributary interfaces and the MSE1_16 provides 16 balanced E1
tributary interfaces through a SCSI-100 female connector. The SCSI-100 connector serves the 21 × E1
receive and transmit signals in the PME1_21 and the 16 x E1 receive and transmit signals in the MSE1_16.
I
MPORTANT: The wiring of the SCSI-100 connector in both the PME1_21 and MSE1_16 is
identical. The different is that in the MSE1_16 only the first 16 E1s are used.
ECI Telecom Ltd. Proprietary
Function
Transmit, tributary 18, wire B
Transmit, tributary 18, wire A
Transmit, tributary 19, wire B
Transmit, tributary 19, wire A
Not connected
Not connected
Transmit, tributary 20, wire B
Transmit, tributary 20, wire A
Transmit, tributary 21, wire B
Transmit, tributary 21, wire A
Not connected
Not connected
Not connected
Not connected
Not connected
BRAID
Direction Wire color
Output Brown/Pink ring
Output Red/Pink ring
Output Orange/Pink ring
Output Yellow/Pink ring
--- ---
--- ---
Output Green/Pink ring
Output Blue/Pink ring
Output Light Gray/Pink ring
Output White/Pink ring
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
Connection Data
8-10
