When a flow rate is decreasing and an actual flow rate goes below 0.95 [m
rate is reduced to 0.0 [m
increasing and the actual flow rate goes over 1.05 [m
Output [m /h]
3
1
0
0.95
NOTE
Note that the totalization might be counted due to the influence of the output fluctuation near 0%
output if a small low-cut value is set.
In particular, if the value of the flow rate span, damping time constant or conductivity is low, the
totalization is easily counted when the flow rate is zero. In such a case, increase the flow rate
span, damping time constant, or low-cut value.
NOTE
If the output process value to be output is changed, it is necessary to specify the low-cut value
again.
5.1.8

Sensor's Nominal Size Setting

To combine the remote transmitter with other remote sensor, the nominal size of the remote
sensor must be set.
The setting can be configured with the following parameters.
Menu path
Display
F
OUNDATION
Fieldbus
Block Relative
Name Index
STB 57
STB 58
NOTE
For the integral type, do not change the nominal size and its unit since they are set at factory
shipment.
/h] with the low-cut function. On the other hand, when a flow rate is
3
(1)
Hysteresis
(2)
1 %
Input [m /h]
3
1.05
1
Device setup ► Detailed setup ► Sensor ► (see below)
Device Configuration ► STB ► Device Configuration ► Configuration ► Sensor ► (see
below)
Display
Nominal size unit
Nominal size
/h], a flow rate is output.
3
F0401.ai
Parameter
F Fieldbus
OUNDATION
Nominal Size Unit
Nominal Size
<5. Functions>
/h], the output flow
3
Description
Specifies the unit of the
nominal size.
Specifies the nominal size.
IM 01E21A02-03EN
