STS Module

The hot swappable STS module has been installed inside the UPS in the Delta factory
before shipment. Please see Figure 5-20 for its location.
STS Module × 1
Modulon DPH Series
External Battery Cabinet Status
Battery Under Temperature
Battery Disconnected (Missing)
Battery Over Charged
Battery Test Fail
Battery End of Discharge Imminent
Battery End of Discharge
Battery Life Time Expired
(Internal View with Two Front Doors Open)
(Figure 5-20: STS Module Location)
