Delta Amplon RT Series User Manual

Single phase 5/6/8/10 kva
Hide thumbs Also See for Amplon RT Series:
Table of Contents

Advertisement

Quick Links

The power behind competitiveness
Delta UPS - Amplon Family
RT Series, Single Phase
5/ 6/ 8/ 10 kVA
User Manual
www.deltapowersolutions.com
E S
C
E S
C

Advertisement

Table of Contents
loading

Related Manuals for Delta Amplon RT Series

Summary of Contents for Delta Amplon RT Series

  • Page 1 The power behind competitiveness Delta UPS - Amplon Family RT Series, Single Phase 5/ 6/ 8/ 10 kVA User Manual www.deltapowersolutions.com...
  • Page 2 Failure to heed these instructions and warnings will void the warranty. Copyright © 2019 by Delta Electronics Inc. All Rights Reserved. All rights of this User Manual (“Manual”), including but not limited to the contents, information, and figures are solely owned and reserved by Delta Electronics Inc.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Chapter 1 : Important Safety Instructions --------------------------- 1 Safety Instructions ------------------------------------------------------1 Standard Compliance --------------------------------------------------4 Storage --------------------------------------------------------------------4 Chapter 2 : Introduction --------------------------------------------------- 5 General Overview ------------------------------------------------------5 Exterior & Dimensions -------------------------------------------------5 Package List -------------------------------------------------------------6 Chapter 3 : Operation Panel ---------------------------------------------- 8 LED Indicators -----------------------------------------------------------8 Multi-function Buttons --------------------------------------------------9 LCD Display ------------------------------------------------------------ 12...
  • Page 4 Chapter 10 : Optional Accessories -----------------------------------60 Chapter 11 : Troubleshooting -------------------------------------------61 Chapter 12 : Maintenance ------------------------------------------------63 12.1 UPS ---------------------------------------------------------------------- 63 12.2 Batteries ----------------------------------------------------------------- 63 12.3 Fans ---------------------------------------------------------------------- 64 Appendix 1 : Technical Specifications-------------------------------65 Appendix 2 : Warranty ----------------------------------------------------67 Amplon RT Series...

  • Page 5: Chapter 1 : Important Safety Instructions

    Chapter 1 Important Safety Instructions Chapter 1 : Important Safety Instructions 1.1 Safety Instructions Installation Warnings Before installation and usage, please read this User Manual thoroughly. This helps you to use the product correctly and safely. Install the UPS in a well-ventilated area, away from excess moisture, heat, dust, flammable gas or explosives.
  • Page 6 NOTE : If you use the UPS in an area that generates or incurs dust, you should install two dust filters (optional) in the 5/ 6/ 8/ 10kVA UPS to ensure normal product life and function. Amplon RT Series...
  • Page 7 Chapter 1 Important Safety Instructions Battery Warnings Keep the batteries away from heat sources. Do not open or mutilate the batter- ies. Do not dispose of batteries in a fire. The batteries may explode. The released electrolyte is harmful to the skin and eyes and may be toxic. A battery can present a risk of electric shock and high short-circuit current.

  • Page 8: Standard Compliance

    100 % NOTE : After storage and before start-up of the UPS, you must allow the UPS to adjust to room temperature (20°C~25°C or 68°F~77°F) for at least one hour to avoid moisture condensing inside the UPS. Amplon RT Series...

  • Page 9: Chapter 2 : Introduction

    Chapter 2 Introduction Chapter 2 : Introduction 2.1 General Overview The RT series UPS is a single-phase input, single-phase output on-line uninterrupt- ible power supply which provides reliable and consistent sine-wave quality power to your electronic equipment. It adopts the latest technology and the highest quality components providing output power factor up to unity, and its efficiency in on-line mode reaches up to 96%.

  • Page 10: Package List

    UPS502R2RT2N035 & UPS502R2RT2N0B0 & UPS502R2RT2N0B8 & UPS602R2RT2N035 & UPS602R2RT2N0B0 & UPS602R2RT2N0B8 & UPS802R2RT2N035 & UPS802R2RT2N0B0 & UPS802R2RT2N0B8 & UPS103R2RT2N035 & UPS103R2RT2N0B0 & UPS103R2RT2N0B8 The power behind competitiveness Delta UPS - Amplon Family RT Series, Single Phase 5/ 6/ 8/ 10 kVA User Manual www.deltapowersolutions.com...
  • Page 11 Chapter 2 Introduction Item 5/ 6/ 8/ 10kVA 1 PC Bracket Ear for UPS 1 SET Tower Stand 4 PCS Pluggable Terminal 2 PCS User Manual 1 PC Parallel Cable 1 PC Battery Cable 1 PC Cord End Terminal 9 PCS USB Cable 1 PC Screw (for fixing the battery cable)

  • Page 12: Chapter 3 : Operation Panel

    1. ON: The UPS detects an internal fault or an environmental fault. 2. OFF: The UPS is in normal state. 3. Flashing: The UPS shows the warning message(s). Please check the corresponding warning message(s) in Chapter 11: Troubleshooting. Amplon RT Series...

  • Page 13: Multi-Function Buttons

    Chapter 3 Operation Panel 3.2 Multi-function Buttons Multi- function Description Button The button has multiple functions. Please refer to the following for detailed information. 1. Turn-on In standby/ bypass mode, press and hold the button for 3 seconds, release it after you hear one beep and the UPS will run in on-line mode.
  • Page 14 3 (see Figure 9-1: Menu Tree), which contains Scrolling related Output information. Up Button In setup up mode, the button is used to navigate the set- ting items. Press the button for 0.1 second to go to the previous setting item. Amplon RT Series...
  • Page 15 Chapter 3 Operation Panel Multi- function Description Button The button is also used to navigate or set up the setting parameter. Press the button for 0.1 second to go to the previous display or to increase a number. If the button is pressed for more than 2 seconds, the number will be in- creased single digit every 0.2 second automatically until the button is released or the number reaches its highest...

  • Page 16: Lcd Display

    NOTE : If the LCD display goes dim, press any button mentioned above for 0.1 second to wake up the LCD display and enable each button function. 3.3 LCD Display ONLINE Input 232.0V 50.0Hz Output 230.0V 50.0Hz Amplon RT Series...

  • Page 17: Icon/ Display Definition

    Chapter 3 Operation Panel 3.3.1 Icon/ Display Definition Icon/ Display Description 1. ON: The UPS is in parallel mode. 2. OFF: The UPS is in single mode. NOTE : For the Master UPS, the icon will flash during parallel mode. For the Slave UPS, the icon will illuminate, not flash, during parallel mode.

  • Page 18: Operation Mode Diagram Definition

    Output 232.0V 50.0Hz even if the UPS transfers to online mode or battery mode. BATTERY Runtime Indicates BATTERY mode. Input 0.0V 0.0Hz Output 230.0V 50.0Hz BYPASS Indicates BYPASS mode. Input 232.0V 50.0Hz Output 232.0V 50.0Hz Amplon RT Series...
  • Page 19 Chapter 3 Operation Panel Diagram Description STANDBY Indicates AC STANDBY mode. 100 % Input 232.0V 50.0Hz Output 0.0V 0.0Hz Indicates Frequency Conversion mode. NOTE : Freq. Conv. In Frequency Conversion mode, the diagram’s power flow will change according to the UPS input voltage and frequency.

  • Page 20: Chapter 4 : Rear Panel

    (Figure 4-1: 5kVA Rear Panel) Item Functions For installation of an optional card, such as Mini SNMP IPv6 card, Mini Relay I/O card, or Mini MINI Slot MODBUS card. For more information, please refer to Chapter 5: Communication Interfaces. Amplon RT Series...
  • Page 21 Chapter 4 Rear Panel Item Functions For UPS parallel communication. For more information, please refer to Chapter 5: Communication Interfaces. Parallel Ports NOTE : To enhance parallel reliability, please adopt the Daisy Chain method to execute parallel configuration. 1. Output dry contacts: Receive the UPS’s event information to indicate the UPS status or internal messages.
  • Page 22 2. When the UPS is working in single- unit mode, the output terminal block has load bank function. The load bank function will be disabled when the UPS is running in parallel mode. Amplon RT Series...

  • Page 23: Chapter 5 : Communication Interfaces

    Chapter 5 Communication Interfaces Chapter 5 : Communication Interfaces NOTE : 1. The UPS can still function properly without making the connections below. 2. For the location of the following communication interfaces, please refer to Figure 4-1~Figure 4-2. 5.1 MINI Slot The MINI slot is for mini-size cards.

  • Page 24: Rs-232 Port

    You can download the software from the following link: http://www.deltapowersolutions.com/en/mcis/ups-software.php. 2. Do not use the USB port and the RS-232 port simultaneously. If you connect the USB cable (user-supplied) to the USB port, the RS-232 port will be disabled right away. Amplon RT Series...

  • Page 25: Usb Port

    Chapter 5 Communication Interfaces 5.6 USB Port Please use the provided USB cable to connect the UPS with a computer and install the UPSentry 2012 software* to check and monitor the UPS status. The USB port has the following functions: 1.

  • Page 26: External Battery Connector

    2. If you need to modify the charge current default setting, please contact your local dealer or customer service. 5kVA/ 6kVA UPS Level 1 Level 2 Level 3 Level 4 Total Battery 5~9Ah 9~17Ah 18~30Ah 27~40Ah Capacity Charge Current Amplon RT Series...
  • Page 27 Charge Current 1.5A External Battery Pack 1. Delta external battery pack is optional. Please refer to the Quick Guide, User Manual or Installation & Operation Guide included in the package of the external battery pack. 2. When connecting the external battery pack with the UPS, you must install an appropriate non-fuse DC breaker or the fast-acting fuse that meets the safety certification.
  • Page 28 Route: press the button for 0.1 second → select → select Maintenance Test → select Start Battery Test. Fore relevant information, please refer to 9.2 Main Menu. Amplon RT Series...

  • Page 29: Chapter 6 : Installation

    Chapter 6 Installation Chapter 6 : Installation Please refer to the system block diagram and related information below for correct installation. Bypass Inverter relay A2D&D2D Inverter Input relay Output load 1 Output Input I/ P Output load 2 Output relay Communication Board To A2D/D2D...
  • Page 30 : Fix the rail on the rack. Step : Insert the UPS in the rack and tighten the screws. If you want to use a non-Delta rail kit, please only follow step (Figure 6-2: Rack Mounting) NOTE : If you need the optional rail kit, please contact your local dealer.

  • Page 31: Tower Mounting

    (see Figure 6-4). Delta Logo Nameplate Panel (Figure 6-4: Rotate the Control Panel and the Delta Logo Nameplate) Carefully lift the whole unit upright with the Delta logo nameplates and the icons shown on the panels facing up.
  • Page 32 Place the whole unit inside the tower stands (Figure 6-6: Place the Whole Unit inside the Tower Stands) Leave adequate space (at least 50cm) around all sides of the unit for good ventilation. NOTE : A minimum of two people are required to execute Amplon RT Series...

  • Page 33: Chapter 7 : Connection And Wiring

    Chapter 7 Connection and Wiring Chapter 7 : Connection and Wiring 7.1 UPS Connection Warnings When connecting the UPS to the mains and the loads, it is highly recom- mended that you install the protective devices. Please refer to the table below and Figure 7-3.
  • Page 34 To avoid the risk of electric shock resulted from the backfeed, installation of a backfeed protection device between the AC input and the UPS is highly recommended. Amplon RT Series...
  • Page 35 Chapter 7 Connection and Wiring NOTE : 1. The UPS doesn’t have any built-in backfeed protection device. Installation of the backfeed protection device between the AC input and the UPS is highly recommended. 2. If there is no backfeed protection device installed between the AC input and the UPS, please (1) attach a warning label on the switch or breaker that controls the AC power supplying to the UPS, and (2) check if any hazardous voltage exists on any terminals connected to...

  • Page 36: Single Unit Wiring

    According to the capacity and the model of your UPS, select proper input and output cables. Connect the main AC source/ output/ external battery pack cables to the wiring terminal block. Please refer to Figure 7-3. Ground the UPS. Amplon RT Series...

  • Page 37: Parallel Units Wiring

    Chapter 7 Connection and Wiring -4 8 -2 3 (L ) For Grounding (N ) 1 (P T -P 2 (N (L ) Output (N ) Protective Devices For Grounding For Grounding Loads Loads Input Utility AC Protective Power Device (Figure 7-3: Single Unit Wiring Diagram) 7.4 Parallel Units Wiring NOTE :...

  • Page 38: External Battery Pack Connection

    DC breaker or the fast-acting fuse that meets the safety certification. Do not use an AC breaker. 2. The breaker must be a 2-pole non-fuse DC breaker with characteristics of 1-pole 250Vdc, 2-pole 500Vdc and 35kA (or above) DC breaking capacity. Amplon RT Series...
  • Page 39 Chapter 7 Connection and Wiring Remove the two screws from the external battery connector’s panel shown below. Two Screws PARALLEL PARALLEL DRY CONTACT RS-232 REPO RS-485 TMOV External Battery Connector’s Panel (Figure 7-5: Remove External Battery Connector’s Panel) Insert the provided battery cable into the external battery connector and use the provided two screws and two standoffs to firmly fix the battery cable After Removal of...

  • Page 40: Chapter 8 : Operation

    Press and hold the ON/ OFF button ( ) for 3 seconds to start up the UPS. Release the button after you hear one beep and the UPS will start up. After the UPS performs self-diagnosis, the UPS will run in ON-LINE mode. Amplon RT Series...

  • Page 41: Start-Up With Batteries (Single Unit)

    Chapter 8 Operation BYPASS Input 232.0V 50.0Hz Output 232.0V 50.0Hz Press and hold the button for 3 seconds and release it after you hear one beep. Self Diagnosis In Progress... ONLINE 0x1012 Battery Test Fail Once the UPS runs normally, switch on the output protective devices (see Figure 7-3) installed between the UPS and the loads.

  • Page 42: Single Unit Turn-Off

    ) for 3 seconds, (2) release it after you hear one beep, (3) use the Scrolling UP or Down button ( ) to se- lect ' Yes ' , and (4) press the Enter button ( ) to confirm your selection. Amplon RT Series...

  • Page 43: Parallel Units Start-Up

    Chapter 8 Operation Switch off the input breaker, input protective device (see Figure 7-3) and output protective devices (see Figure 7-3). After the LCD backlight goes dim and the fans stop completely, switch off the battery breaker to ensure that there is no remaining battery power. 8.3 Parallel Units Start-up NOTE : 1.

  • Page 44: Start-Up With Batteries (Parallel Unit)

    Figure 7-3. After the LCD backlight goes dim and the fans stop completely, the parallel system will completely shut down. Switch off each UPS’s external battery breaker or disconnect all external battery cables from the parallel UPSs to ensure that there is no remaining Amplon RT Series...

  • Page 45: Operation Mode

    Chapter 8 Operation battery power. 8.5 Operation Mode Standby Mode After the UPS is connected to the utility AC power, it will supply power to the UPS and the batteries will be charged. Online Mode In on-line mode, the connected loads are supplied by the inverter, which derives its power from the utility AC power, and the UPS charges the batteries and provides power protection to its connected loads.

  • Page 46: Chapter 9 : Lcd Display & Settings

    Language, Date & Time, Output Setting, External Battery Type and External Battery Capacity settings, the LCD display will move to the Main Screen that shows the current operation mode. The following flow chart helps you to navigate the LCD screen. Amplon RT Series...
  • Page 47 The Initial Setting Screen will no longer appear after initial configuration. Next time, when the UPS is powered on, the LCD display will show DELTA welcome page for 3 seconds and then directly go to the Main Screen that shows the current operation...

  • Page 48: Main Menu

    In the Main Screen, press the button for 0.1 second to enter the Main Menu. You can set up relevant items here. Measurement Setting Main Menu Control Maintenance NOTE : Please note that only qualified service personnel can perform setup actions. Amplon RT Series...
  • Page 49 Chapter 9 LCD Display & Settings For setup procedures, please refer to the following: In the Main Menu, select the item you want to configure, press the ENTER button for 0.1 second and the UPS will enter the setup mode. Press the button for 0.1 second or press the button for 0.1 second to...
  • Page 50 Dry Contact Setting Dry Contact 1 – Input/ Dry Contact 2 – Output/ Dry Contact 3 – Output/ Dry Contact 4 – Output/ Remote Control (Level 2) Component Life Prediction Fan Life Prediction (Figure 9-1: Menu Tree) Amplon RT Series...

  • Page 51: Measurement Menu

    Chapter 9 LCD Display & Settings 9.2.1 Measurement Menu In Main Menu, after selecting , press the button to enter the Measurement Measurement Menu. The Measurement Menu displays the UPS’s status readings, such as Output, Input, Bypass and Battery information. Output Measurement Setting...
  • Page 52 Output Sync. Freq. Range. 3. * : When the Output Frequency is set as Converter-50Hz/ Converter-60Hz, the UPS will enter the Frequency Conversion mode and the bypass output will become Disable. Amplon RT Series...
  • Page 53 Chapter 9 LCD Display & Settings Input Setup Item Selectable Value Default Value Bypass Max. Voltage +10/ 15/ 20% +15% Bypass Min. Voltage -10/ 15/ 20/ 25/ 30/ 35/ 40% -20% ECO Mode Setup Item Selectable Value Default Value ECO Mode Disable/ Enable Disable ECO Max.
  • Page 54 For 5K/ 6K: 1/ 2/ 3/ 4/ 5/ 6/ 7/ 8A* 1A (5K/ 6K)* Current For 8K/ 10K: 1.5/ 2/ 3/ 4/ 5/ 6A 1.5A (8K/ 10K)* Standard battery pack/ External Battery Type * Customer own batt. pack Amplon RT Series...
  • Page 55 Chapter 9 LCD Display & Settings Setup Item Selectable Value Default Value Standard battery pack: Part Number Quantity External Battery Capacity Customer own batt. pack: Battery Voltage Capacity Install date YYYY/ MM/ DD NOTE : : Under the condition of rated battery voltage ≤ 192Vdc. : For suffix B0 model, its charge current default setting is 4A.
  • Page 56 OK/ Load protected/ Load powered/ General alarm/ 4 - Output alarm Overload alarm Option 1: REPO/ ROO Option 2: Option 2: Remote REPO/ Normally open/ delay time 0-999sec Control Normally closed (step: 1 sec) (For REPO) (For ROO) Amplon RT Series...

  • Page 57: Control Menu

    Chapter 9 LCD Display & Settings NOTE : : For detailed information about option 1, please contact service personnel. Component Life Prediction Setup Item Selectable Value Default Value Fan Life Prediction No/ Yes 9.2.3 Control Menu In Main Menu, after selecting , press the button to enter the Control Menu.
  • Page 58 → Output → Outlet Group 1 → Output Reboot Immediately → Yes. Control - Output Outlet Group 1 Bypass - Output - Main Output Reboot Immediately Output Reboot With Delay Output Reboot Output Reboot immediately immediately UPS will reboot immediately UPS will reboot immediately Cancel Cancel Reboot Amplon RT Series...

  • Page 59: Maintenance Menu

    Chapter 9 LCD Display & Settings 9.2.4 Maintenance Menu In Main Menu, after selecting , press the button to enter the Maintenance Maintenance Menu. 1 /2 Test Measurement Setting Battery Aging Reset Maintenance Control 2 /2 About...
  • Page 60 Date/ Time, Average load (W), Battery Aging Item, Output Actual discharging Battery Discharging power, Total time, History discharging time Estimated remaining time, Total discharging time Reset Power Usage Yes/ Cancel Calculator Reset Restore Factory Yes/ Cancel Setting Amplon RT Series...
  • Page 61 Chapter 9 LCD Display & Settings LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5 Description, Event code Event List Error Description YYYY/MM/DD HH:MM:SS Clear Log Yes/Cancel Model Name: RT-5K UPS - Part No. UPS502R2RT0B035 UPS - Serial No. 1BA0150001 Maintenance UPS - Manufacture...
  • Page 62 Test In Progress... Battery 272.0V Press ESC key to abort test Battery Test Test In Progress... Battery 272.0V Press ESC key to abort test Battery Test Test In Progress... Battery 272.0V Press ESC key to abort test Test Completed Amplon RT Series...
  • Page 63 Chapter 9 LCD Display & Settings Once the test is completed, the test result will be shown as follows. A. Test Result_ Fail: The alarm icon will show in the left bottom of the LCD display. B. Tests Result_ Pass: No alarm icon occurs, and the UPS runs normally. Battery Test Battery Test Battery Test...

  • Page 64: Chapter 10 : Optional Accessories

    Quick Guide, User Guide, or Installation & Operation Guide included in the package of the relevant optional accessory. 2. If you want to buy any accessory mentioned above, please contact your local dealer or customer service. Amplon RT Series...

  • Page 65: Chapter 11 : Troubleshooting

    1. When a problem occurs, please check if following situations exist before contacting Delta service personnel: Is the main input voltage present? 2. Please have the following information ready if you would like to contact the Delta service personnel: Unit information including model, serial number, etc.
  • Page 66 0X1003 pack(s). Disconnected pack(s). 2. The battery/ 2. Contact service batteries is (are) personnel. damaged. NOTE : If all possible causes are eliminated but the alarm still appears, please contact your local dealer or customer service. Amplon RT Series...

  • Page 67: Chapter 12 : Maintenance

    Chapter 12 Maintenance Chapter 12 : Maintenance 12.1 UPS UPS Cleaning Regularly clean the UPS, especially the slits and openings, to ensure that the air freely flows into the UPS to avoid overheating. If necessary, use an air-gun to clean the slits and openings to prevent any object from blocking or covering these areas.

  • Page 68: Fans

    UPS. If not, contact service personnel to replace the fans. NOTE : Please ask your local dealer or customer service for more maintenance information. Do not perform maintenance if you are not trained for it. Amplon RT Series...

  • Page 69: Appendix 1 : Technical Specifications

    Appendix 1 Technical Specifications Appendix 1 : Technical Specifications Model RT-5K RT-6K RT-8K RT-10K Power Rating 5kVA/5kW 6kVA/6kW 8kVA/8kW 10kVA/10kW Waveform Pure Sinewave Nominal 200/208/220/230/240 Vac Voltage Voltage 175 ~ 280Vac (100% load); Range 100 ~ 175Vac (50% ~ 100% load) Frequency 50/60 Hz ±...
  • Page 70 : When the operating temperature is at 40 ~ 55°C (104 ~ 131°F), the UPS will be de-rated to 75% of its capacity. 4. Please refer to the rating label for the safety rating. 5. All specifications are subject to change without prior notice. Amplon RT Series...

  • Page 71: Appendix 2 : Warranty

    Appendix 2 Warranty Appendix 2 : Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship within the warranty period. If the product has any failure problem within the warranty period, Seller will repair or replace the product at its sole discretion according to the failure situation.
