(STS Module Left Side View)
Lock
Left
Indentation
5.7.3 STS Module's LED Indicator
The STS module's LED indicator shows its operation status. Please refer to the following
table.
OFF
ON (yellow)
Flashing (yellow)_ on for 0.3
NOTE:
In bypass mode, if you turn the STS module's switch to the lower position (
Modulon DPH Series
(Figure 5-30: Location of the Lock and Lateral Indentation)
(STS Module Left Side View)
(Figure 5-31: Location of the STS Module's LED Indicator)
LED Indicator
(STS Module Right Side View)
LED
Indicator
Description
The STS module is OFF.
The STS module is working in bypass mode,
ECO mode, or energy recycle mode.
The STS module is abnormal.
5-32
Lock
Right
Indentation
), the
