Description of cable types

190
The Cable Type selection in the CONFIG > Physical Layer Settings menu enables
you to specify the type of cable that most closely matches the cable used to
connect the signal source to the instrument. The following is a list of supported
cable type descriptions:
Belden 8281. Coax-Double Braided RG-59/U Type Number of Coax: 1 RG
Type: 59/U AWG: 20 Stranding: Solid Conductor Material: BC- Bare Copper
Insulation Material: PE-Polyethylene Outer Shield Material: TC-Tinned
Copper/TC-Tinned Copper Outer Jacket Material: PE-Polyethylene Plenum
(Y/N): N Plenum Number: 88281 Nom. Characteristic Impedance: 75 ohm
Applications: Precision Video Cable for Analog and Digital, Double Braided
RG-59/U Type, Broadband Coax, Headend/Video Cables, Precision Video
Cable for Analog and Digital, RG-59/U Type
Belden 1694A. Coax-Low Loss Serial Digital Coax Number of Coax: 1 RG
Type: 6/U AWG: 18 Stranding: Solid Conductor Material: BC-Bare Copper
Insulation Material: Gas-injected FHDPE-Foam High Density Polyethylene
Outer Shield Material Trade Name: Duofoil: Outer Shield Material:
Aluminum Foil-Polyester Tape-Aluminum Foil/TC-Tinned Copper Outer
Jacket Material: PVC-Polyvinyl Chloride Plenum (Y/N): N Plenum Number:
1695A Nom. Characteristic Impedance: 75 ohm Applications: Precision
Video Cable for Analog and Digital, Low Loss Serial Digital Coax, Video
Cable, Precision Video Cables for Analog and Digital Applications, Precision
Video Cable for Analog and Digital, RG-6/U Type
Belden 1505. Coax-RG-59/U Type Number of Coax: 1 RG Type: 59/U
AWG: 20 Stranding: Solid Conductor Material: BC-Bare Copper Insulation
Material: Gas-injected FHDPE-Foam High Density Polyethylene Outer
Shield Material Trade Name: Duofoil: Outer Shield Material: Aluminum
Foil-Polyester Tape-Aluminum Foil/TC-Tinned Copper Outer Jacket
Material: PVC-Polyvinyl Chloride Plenum (Y/N): N Plenum Number: 1506A
Nom. Characteristic Impedance: 75 ohm Applications: Broadband Coax,
Headend/Video Cables, Video Cable, Precision Video Cables for Analog and
Digital Applications, Precision Video Cable for Analog and Digital, RG-59/U
Type
