Display information
80
Err Secs: The number of seconds since the last reset that contained at least
one error.
Err Fields: The number of fields, since the last reset, that contained at least
one error.
% Err Fields: Displays a calculated number showing the percentage of all
fields since the last reset that contained at least one error.
Data Collection: Displays the state of error gathering. Possible states are:
Running – Indicates errors are being gathered and displayed on the
status page.
Stopped – Indicates errors are not being gathered and the status page
is not being updated.
Resetting – Appears briefly after SEL has been pressed to reset the
statistics.
Run Time: The time since the last reset occurred. Time is displayed as "DD,
HH:MM:SS", where DD is the number of days, HH is the number of hours,
MM is the number of minutes, and SS is the number of seconds.
Frozen: This readout appears only when you press FREEZE or CAPTURE
and indicates that errors are being gathered but are not being displayed on the
Status page. This state is useful for looking at EDH (Error Detection and
Handling) and CRC (Cyclic Redundancy Check) values on live video.
Video Session pop-up menu.
NOTE.
To reset, stop, or start an individual video or audio session, select the
tile in which it is displayed and use the SEL button, right arrow key, and left
arrow key, respectively. Remember that the STATUS pop-up menu must be closed;
otherwise, the button and key presses will navigate through that menu.
Mute Alarms: Mutes alarms for all Status display types.
All Sessions Reset: Globally resets any and all video sessions displayed in all
panes, regardless of the display and session from which it is executed.
All Sessions Start: Globally starts any and all stopped video sessions
displayed in all panes, regardless of the display and session from which it
is executed.
All Sessions Stop: Globally stops any and all stopped video sessions
displayed in all panes, regardless of the display and session from which it
is executed.
