USB software installation
WVR8200 and WVR8300 User Manual
5. Download the latest version to your PC.
6. After the software package is downloaded, click on the self-extracting archive
to extract the following files into the directory of your choice: transfer.exe
and firmware.pkg. There may also be a readme.txt file.
To perform the upgrade, you can use either the USB Software Installation
procedure or the Network Software Installation procedure. The time required to
complete the upgrade is about 25 minutes.
CAUTION.
Once the instrument has started to erase internal flash, DO NOT
remove power from the instrument. If you do so, the instrument flash will be
corrupted. The instrument will have to be sent to a Tektronix factory service
center to have the system software restored.
NOTE.
If power to the instrument is lost before it begins erasing the internal flash,
you can restart the software upgrade after the instrument reboots.
The first time an instrument is upgraded to software version 3.X, the upgrade
process must be run two times.
Use the following steps to upgrade the instrument software using a USB memory
device.
1. Insert the USB memory device into a USB port (of the PC containing the
latest software).
2. On the PC, navigate to the USB device.
3. On the USB device, create a directory named:
WfmUpgrd
NOTE. To avoid upgrade problems, be sure to name the WfmUpgrd directory
exactly as shown.
4. Open the WfmUpgrd directory and copy the firmware.pkg file (from the
extracted archive) to the USB device.
You should have a directory path
5. Safely remove the USB device from the PC and insert it into the USB port
on the front panel of the instrument.
WfmUpgrd\firmware.pkg
Functions
.
115
