Getting started
SNMP setup
10
If you intend to use SNMP commands to control the instrument (SNMP control
is primarily intended for access through automation systems), you must set up
SNMP parameters.
NOTE.
The WVR8200 and WVR8300 wfm_mon.mib and the wvr8000.mib
contain SNMP OIDs and can be downloaded from the instrument Web
page. You can also download a printable version of the MIB manual from
www.tektronix.com/manuals.
The procedure to set SNMP settings is similar to the procedure for IP settings.
(See page 9, Connection and IP settings.)
This table shows the parameters that can be set.
Setting
SNMP Enable
SNMP Trap Enable
SNMP Trap Address
Private Community String
Public Community String
Description
This entry in the Network Settings part of the Configuration menu
allows you to turn on or off the remote access through SNMP.
This menu entry allows you to turn on or off the traps that are
sent out through SNMP.
This menu entry allows you to set IP addresses to which SNMP
traps are sent through SNMP. Traps can be sent to up to four
addresses when error conditions are detected.
NOTE.
A value of all zeroes for the address will disable that
trap output.
This menu entry allows you to set the Private Community string.
This string is effectively a password. Without this string, SNMP
commands cannot change values in the instrument.
NOTE.
The Private String is necessary for SNMP access to
write changes into the instrument.
This menu entry allows you to set the Public Community string.
This string is effectively a password. Without this string, SNMP
commands cannot read values from the instrument.
NOTE.
The Public String is necessary for SNMP access to
read values from the instrument.
